Screw Second Header Punch , Recess Header Punches Good Wear Resistance

Screw Second Header Punch , Recess Header Punches Good Wear Resistance

screw header punch

second header punch

Place of Origin:

Chongqing, China

Brand Name:

Henghui

Certification:

ISO9001:2015

Model Number:

customized

Contact Us

Request A Quote
Product Details
Shaping Mode:
Forging Mould
Other Name:
Header Punch
Material:
M2 Or M42
Plating:
TiN, TiALN
Size:
D=12, 14, 18, 23
Hardness:
HRC60-68
Port:
Chongqing
Payment & Shipping Terms
Minimum Order Quantity
50 pcs
Price
USD+Negotioned+Pieces
Packaging Details
carton case or wooden case
Delivery Time
5-10 days
Payment Terms
T/T, Western Union
Supply Ability
1000000 Piece/Pieces per Month
Product Description
Screw Second Header Punch , Recess Header Punches Good Wear Resistance

Product Description

Please specify the details of header punches as follows when you inquire or order:
1. The material of header punches you need or the material of screw you used;
2. The specification of standard you use, for examples: JIS, ANSI or DIN;
3. Screw Application: Machine Screw , Tapping Screw , Wood Screw or any others;
4. Head Style: Flat head , Pan head , Truss head , Binding head or any others;
5. Nominal Size: JIS-M20, M23; ANSI-#4, #8; DIN-M30, M35;
6. Recess Driver: Phillips , Slot, Phillips and Slot Combination, Pozi ect;
7. Dimension : 12x25, 14x25, 18x25, 23x25;
8. Coated : Plian , TIN Coated , TILAN Coated.

 Screw Second Header Punch , Recess Header Punches Good Wear Resistance 0

Parameter

Header punch standard:
JIS, ANSI, DIN, ISO, BS, GB, and NON-STANDARD .
The common head style:
Flat head, pan head , oval head , binding head , round head, truss head, button head, pf head, cheese head, fillister head and so on .
The common driver:
Phillips , Phillips and slot combination, slotted, hexagon, six-lobe (torx), six-lobe tamper , six-lobe/slot , pozidriv , square, square/slot , Phillips/square, triangle and so on .
The coating about the screw header punch:
Without coating,
With TIN coating-yellow coated,
With TILAN coating-black coated
The standard size:
12x25mm
14x25mm
18x25mm
23x25mm
The unit weight about the header punch:
12x25mm: 25g/pc
14x25mm: 30g/pc
18x25mm: 50g/pc
23x25mm: 80g/pc

Company Information

   Being a highly effective and fast-moving firm, Henghui is actively engrossed in offering an exclusive assortment of Hex Segmental Dies. The offered products are highly acclaimed across the globe for their optimum quality and easy installation. Manufactured under innovative professionals with advanced techniques, these dies are used in various in various industries for making varied types of fasteners. Apart from this, the products offered by us are available in diverse sizes as per client's demands.

Certifications

 Screw Second Header Punch , Recess Header Punches Good Wear Resistance 1

FAQ

Q1:Are you a factory or trading company?
A1:We are a factory, Henghui has 7,00 square meters of manufacturing plants and R&D bases
Q2:Where is your factory located? How can I visit there?
A2:Our factory is located in Hailong Village, Baishiyi Town, Jiulongpo District, Chongqing City, China. All our clients, from home or abroad, are warmly welcome to visit us at anytime!
Q3:What is the material of your products?
A3:The material is carbide and high speed steel,like VA80,G6,ST7,DC53,SKD11,D2,SKH-9,SKH-51, or as our clients’ requirements.
Q4: The maximum press your factory have available ?
A4: Our factory has 30T,60T,160T punching machines
Q5::How does your factory do regarding quality control?
A5: Quality is priority. we having gained ISO 9001 Quality Authentication Certificate.
