Name: Surface Polishing China New Design Cold Heading Die For Extrusion Die With Medium Carbide Material
Brand: Chongqing Henghui Precision Mold Co., Limited
SKU: Customized
Price: 52.00 USD
Availability: InStock

Home > products > Cold Heading Die >

Surface Polishing China New Design Cold Heading Die For Extrusion Die With Medium Carbide Material

Extrusion Die Cold Heading Die

China New Design Cold Heading Die

Medium Carbide Cold Heading Die

Place of Origin:

China,Chongqing

Brand Name:

Henghui

Model Number:

Customized

Request A Quote

Product Details

Mould Material:

SKD61

Technicas:

Sintered

Port:

Chongqing, China

Grinding Accuracy:

0.001mm

Product:

Drawing Dies

Design:

Drawing Offered

Precision:

High Precision

Smart Home:

Molds

Service:

OEM/ODM Customized Size Punch Die

Type:

Cold Heading Die

Durability:

Long Service Life

Shape:

Round

Case Materia:

Tungsten Carbide And Mold Steel

Grinding Precision:

0.01mm

Packing:

Carton

Payment & Shipping Terms

Minimum Order Quantity

10 pieces

Price

usd 5-100 pieces

Packaging Details

as client's requirement

Delivery Time

10-15days

Payment Terms

T/T,

Supply Ability

1000 pieces per Month

High-Speed Steel (HSS) Cold Heading Die - High Strength Impact Resistant Long Lifespan for Automotive Parts Manufacturing

Get Best Price

High-Restraint Die Cold Heading Die China Supplier Customized Good Quality

Get Best Price

Customized Good Quality Drawing Die Cold Heading Die Tungsten Carbide

Get Best Price

China Factory Customized Good Quality Drawing Die Cold Heading Die Tungsten Carbide

Get Best Price

86-23-60338218-60338218

hou@citool.com

86-023-60338218-60338218

Contact Now

Product Description

Surface Polishing China New Design Cold Heading Die For Extrusion Die With Medium Carbide Material

Products Description

Insert Material:

We can suggest different carbide material according to different usage.

	Item	Co	Grain Size	Density	Hardness	TRS	Impact Strength	Application
Mediun-Grained		Co%	μm	g/cm²	HRA	Kgf/mm²	Kgf/m-cm²
	KG2	6.50%	2~3	14.90	90.5	320	0.28	Drawing die
	KG3	9%	2~3	14.61	89.3	340	0.52	Extrusion die
	KG5	12%	2~3	14.31	88.3	340	0.58	Extrusion die
	KG6	14%	2~3	14.12	87.3	320	0.65	Extrusion die
Coarse-Grained	ST6	15%	3~6	13.80	86.0	270	0.78	Stainless steel
	ST7	20%	2~6	13.40	85.3	270	0.80	Stainless steel
	EA65	18%	2~6	13.73	85.0	300	0.80	Carbon steel screw/cutting die
	VA80	20%	3~6	13.58	84.0	280	0.85	Impact resistance
	VA90	22%	6~9	13.39	82.5	240	0.90	Impact resistance
	EA90	24%	2~6	13.22	82.8	270	0.90	Impact resistance

Case Material:

Our main case material is H13(SKD61) HRC46-48

SKD61(H13)
Chemical Composition	C	Si	Mn	P	S	Cr	Mo	V	W
Content (%)	0.39	1.15	0.44	0.021	0.007	5.12	1.3	0.94	0.06
	Cu	Ni
	0.05	0.06

Surface Treatment:

TiN / TiAlN

Process

Factory

About Us

Chongqing Henghui Precision Mold Co., Ltd. has CNC lathes, CNC machining centers, CNC Cylindrical Grinding Machine, CNC EDM machine, CNC Cutting Machine, Milling Andam Drilling Machine ,etc.We also have various types testing equipment,such as Rockwell Hardness Tester, Projector ,3D Image Measuring Instrument, etc. Henghui using high-quality tungsten carbide material and professional vacuum heat treatment.We design,manufacturing and supply high-quality precision molds for customers who engaged in cold heading and hot upsetting industries.About our molds , the relative standard deviation can be controlled within 0.005mm, concentricity can be controlled within 0.01mm. Strict accordance with ISO9001:2015 quality management system requirements of the operation,can ensure provide timely and high-quality service for our customers.Our products has exported to Southeast Asia,Europe and the United States ."Customer first, quality first, technology first, dedicated service" is our consistent operating principles.Warmly welcome to negotiate business with us.

Exhibition

Exhibition, German Fastener Exhibition, Indian Fastener exhibition and so on. We are committed to participating in various fastener screw exhibitions, and we have gained many new friends in the exhibitions. At the same time, we will visit our new and old customers offline. In each exhibition, we prepared various samples carefully and waited for the exhibition customers, who were satisfied with our products no matter in terms of design, price or quality.

Packing and Delivering

Packaging Details:Carton Box; Export Standard Package, Or As Client's Requirement.

Delivery Detail:According To The Quantity Of The Order, About 12-45 Days.

Inspection equipment

FAQ

Q1: How can I get a quotation from your company?

A1: Contact us.In order to quote you as soon as possible, we need the following information: drawings, Material , Quantity ,Surface treatment.

Q2: What is our lead time?

A2: This will be based on the number of products you customize and the country you are in.
