Name: Industrial Screw Punch Tool Hardened Steel Quick-Change Punch High Precision CNC Machined
Brand: Chongqing Henghui Precision Mold Co., Limited
SKU: Customized
Price: 1.00 USD
Availability: InStock

Home > products > Tungsten Carbide Die >

Industrial Screw Punch Tool Hardened Steel Quick-Change Punch High Precision CNC Machined

Place of Origin:

CHINA

Brand Name:

Heng Hui

Certification:

ISO9001

Model Number:

Customized

Request A Quote

Industrial Screw Punch Tool Hardened Steel Quick-Change Punch High Precision CNC Machined

Product Details

Material:

Steel

Application:

Industry

Size:

Customized Size

Surface Treatment:

Customer's Request

Delivery Time:

15-25 Days

Advantage:

High Strength

Mould Life:

250000-300000shots

Design Software:

2D/3D/CAD/DWG//STEP/PDF/UG

Runner:

Hot Runner/Cold Runner

Payment & Shipping Terms

Minimum Order Quantity

10 PCS

Price

USD 1-2 PCS

Packaging Details

Carton Box

Delivery Time

10-20 Days

Payment Terms

T/T, L/C

Supply Ability

1000 PCS Month

Drill Piont Dies For Precision Stamping High Wear Resistance Drill Point Punching

Get Best Price

Industrial Screw Punch Tool Hardened Steel Quick-Change Punch High Precision CNC Machined

Get Best Price

Restraining Die For Auto/Aerospace Metal Forming - 500K Shots Lifespan ±0.05mm Tolerance 2500T Prestressed

Get Best Price

Shock-Resistant Alloy Steel Punch Collet Chuck - Wearproof Design Multi-Press Fit 50,000+ Cycles

Get Best Price

+8613983025528

sales1@citool.com

86-023-60338218-60338218

Contact Now

Product Description

Products Description

Advantages

Quick and Easy Changeover:
Allows for rapid replacement of worn or damaged punches without disassembling large sections of the die

or requiring specialized press tools. Simply unscrew the old punch and screw in the new one.
Simplified Design Reduced Components:
Eliminates the need for complex punch holders, retainers, set screws, or keys often required for press-fit punches.

The screw thread itself provides the primary retention.
Improved Accuracy Alignment:
Screw threads provide excellent concentricity, ensuring precise alignment of the punch within the die shoe or

stripper plate,leading to better part quality.

Material:M42(H59)＞M35(H55)＞M2(H9)

H9(M2)
Chemical Composition	C	Si	Mn	P	S	Cr	Mo	V	W
Content (%)	0.85	0.33	0.34	0.027	0.005	4.12	4.73	1.78	5.74
	Cu	Ni
	0.12	0.24

M42(SKH59)
Chemical Composition	C	Si	Mn	P	S	Cr	Mo	V	W
Content (%)	1.06	0.3	0.31	0.018	0.002	3.74	9.29	1.1	1.34
	Cu	Ni	Co
	0.07	0.29	7.97

Header punch standard:

JIS, ANSI, DIN, ISO, BS, GB, and NON-STANDARD .
The common head style:
Flat head, pan head , oval head , binding head , round head, truss head, button head, pf head, cheese head, fillister head and so on .
The common driver:
Phillips , Phillips and slot combination, slotted, hexagon, six-lobe (torx), six-lobe tamper , six-lobe/slot , pozidriv , square,
square/slot , Phillips/square, triangle and so on .

Surface Treatment:

Without coating,
With TIN coating-yellow coated,
With TILAN coating-black coated

Standard size	Weight
12x25mm	25g/pc
14x25mm	30g/pc
18x25mm	50g/pc
23x25mm	80g/pc

Process

Factory

Inspection Equipment

FAQ

Q1: How can I get a quotation from your company?
A1: Contact us.In order to quote you as soon as possible, we need the following information: drawings, Material , Quantity,Surface treatment.

Q2: What is our lead time?
A2: This will be based on the number of products you customize and the country you are in.

Q3: What is your minimum order quantity (MOQ)?
A: Our MOQ varies depending on the product. Please contact our sales team for detailed information.

Q4: What payment methods do you accept?
A: We accept various payment methods, including wire transfer (T/T), letter of credit (L/C), and PayPal.
