Tungsten Carbide Punch Pin with TiN Coating for Long Mould Life and High Toughness in Industrial Field

TiN Coating Punch Pin

Long Mould Life Heading Punch

High Toughness Tungsten Carbide Punch

Place of Origin:

Chongqing, China

Certification:

ISO

Model Number:

customized

Request A Quote

Tungsten Carbide Punch Pin with TiN Coating for Long Mould Life and High Toughness in Industrial Field

Product Details

Shaping Mode:

Extrusion Mould

Product Material:

Carbide

Size:

Customized Size

Mould Life:

250000-300000shots

Drawing Format:

2D/(PDF/CAD)3D(IGES/STEP)

MOQ:

Profile Tolerance:

+/-0.006MM~ +/-0.008MM

Surface Treatment:

Polishing,coating Treatment,Nitriding Treatment,measuring,ETC

Hardness:

HRA60-68

Measuring Instruments:

VMS,profile Projector,pressure Gauge,hardness Tester,magnifying Glass

Processing Machinery:

Wire EDM, CNC Milling And Turning, Laser Cutting, Drilling, Grinding, Bending, Stamping, Welding

Drawing Software:

AUTOCAD,pro-engineer,UG,moldflow

Chemical Composition C:

0.85-1.06%

Chemical Composition Cr:

3.74-4.12%

Chemical Composition Mo:

4.73-9.29%

Payment & Shipping Terms

Minimum Order Quantity

Price

Industrial Screw Punch Tool Hardened Steel Quick-Change Punch High Precision CNC Machined

Get Best Price

Customized Cold Heading Nut Mold with Alloy Material and Square Shape for Industrial Applications

Get Best Price

Precision Thread Rolling Die with +/-0.01mm Tolerance High Accuracy and Long Life for Screw Making

Get Best Price

YG15 Material Tungsten Carbide Die with Customized Size and Steel Case for Screw Making

Get Best Price

+8613983025528

hou@citool.com

86-023-60338218-60338218

Contact Now

Product Description

Punch Pin TiN Coating Heading Punch - China Supplier Customized New Design

Our high-quality HSS Punch is manufactured with precision for superior performance in demanding industrial applications. The material selection focuses on high-speed steel to ensure excellent red hardness and wear resistance during high-speed punching operations.

Material Options

We offer multiple material grades to suit various application requirements:

Carbide (Premium grade)
M42 (H59)
M35 (H55)
M2 (H9)

Material Composition

Chemical Composition	C	Si	Mn	P	S	Cr	Mo	V	W
H9(M2) Content (%)	0.85	0.33	0.34	0.027	0.005	4.12	4.73	1.78	5.74
M42(SKH59) Content (%)	1.06	0.3	0.31	0.018	0.002	3.74	9.29	1.1	1.34

Surface Treatment

TILAN coating for enhanced durability

Product Specifications

Feature	Specification
Product Name	HSS Pin Punch
Material	M2/M42/M35/Carbide
Profile tolerance	+/-0.006MM~ +/-0.008MM
Surface treatment	Polishing, coating Treatment, Nitriding treatment
Hardness	HRA60-68
Measuring instruments	VMS, profile projector, pressure gauge, hardness tester
Usage	For making bolts or nuts
Design	Standard or custom according to requirements
Processing machinery	Wire EDM, CNC milling and turning, laser cutting, etc.
Drawing software	AUTOCAD, Pro-Engineer, UG, Moldflow
Application	Machinery equipment, heavy industries, medical, chemical
Quality control	100% inspection before shipping
Customization	OEM/ODM service available
